What Is the AutoClear 5333 X-Ray Machine?

Built for Fast,
Accurate Screening in
Tight Spaces

The AutoClear 5333 is a single-source, multi-energy X-ray inspection system designed to screen mid-sized items such as purses, briefcases, backpacks, strollers, hand-carried items, and small parcels.

Its low-profile, bottom-up generator design makes smaller items appear sharper and larger on screen, helping operators identify potential threats without slowing the line. The patented guided conveyor belt never needs adjusting, which keeps the system running reliably scan after scan.

AutoClear 5333

See the AutoClear 5333 in Action

TECHNICAL SPECIFICATIONS

AutoClear 5333
X-Ray Machine
Full Spec Sheet

Ideal For:

  • Yellow checkmark icon
    Hospitals
  • Yellow checkmark icon
    Arenas / Stadiums
  • Yellow checkmark icon
    Schools / Universities
  • Yellow checkmark icon
    Loss Prevention
  • Yellow checkmark icon
    Courthouses
  • Yellow checkmark icon
    Military Bases
  • Generator Options
    100 kV (standard, operating at 90 kV) · 160 kV (optional, operating at 140 kV)
  • Material Penetration
    10 mm guaranteed at 100 kV · 28 mm guaranteed at 160 kV
  • Resolution
    38 AWG guaranteed wire resolution
  • Contrast Sensitivity
    Over 2 million color tones standard
  • Tunnel Size
    20.8″ x 13.0″ (W x H)
  • Overall Dimensions
    52.4″ x 29.1″ x 44.3″ (L x W x H)
  • Conveyor Speed
    24.0 cm (9.4 in.) per second
  • Pulling Weight
    165 kg (363 lbs.)
  • Net Weight
    275 kg (606 lbs.) at 100 kV · 333 kg (734 lbs.) at 160 kV
  • System Power
    100/115/230 VAC, 60/50 Hz, 0.7 kVA max
  • Operating Temperature
    32°F to 104°F
  • Certifications
    STAC certified; CE/CSA/USsafety/EMC available on request
AutoClear 5333 X-ray Machine Request a Technical Consultation
AutoClear 6040
Why Security Teams Choose the AutoClear 5333

Built for the Checkpoints
Other Systems Can’t Handle

01

A Footprint That Fits Anywhere

The AutoClear 5333 fits elevators, narrow halls, and tight spaces, delivering thorough screening where larger systems can’t.
02

Sharper Images, Smaller Items

As a baggage X-ray machine, it speeds operator decisions and reduces unnecessary secondary inspections for faster checkpoint flow.
03

A Self-Adjusting Conveyor Belt

The patented Auto Tracking conveyor stays calibrated scan after scan, reducing adjustments and keeping throughput steady under heavy demand.
04

Power To Match the Threat

Choose between a standard 100 kV generator for everyday screening or an optional 160 kV generator when you need to see through denser materials.
05

Built on a Stable, Flexible Operating System

The AutoClear 5333 runs on autoSoft, a Linux-based operating system built specifically for X-ray screening.
06

Scalability

The AutoClear 5333 is a security X-ray machine that scales with AI, networking, and remote tools, eliminating the need for system replacement.
Frequently Asked Questions

AutoClear 5333 FAQs

We’ve answered the questions we get most often.
What makes the AutoClear 5333 different from other X-ray inspection systems?

The AutoClear 5333 is built for spaces other systems cannot reach.

Its compact footprint fits into elevators, narrow halls, and tight corridors, while its low profile, bottom-up generator design produces sharper, larger on-screen images of small items, helping operators catch threats faster without slowing the checkpoint.

What size items can the AutoClear 5333 screen?

This baggage x-ray machine is designed for mid-sized items such as purses, briefcases, backpacks, strollers, and small parcels.

Its tunnel measures 20.8 inches wide by 13.0 inches high, and the patented guided conveyor rapidly images full mailbags as well as long or tall items.

What is the difference between the 100 kV and 160 kV generator options?

The standard 100 kV generator, operating at 90 kV, guarantees 10 mm of steel penetration and covers most everyday screening needs.

The optional 160 kV generator, operating at 140 kV, guarantees 28 mm of steel penetration for situations that call for greater material penetration, such as denser packages or higher-risk environments.

Can the AutoClear 5333 detect narcotics and other contraband, not just weapons and explosives?

Yes. Multi-energy color imaging helps distinguish organic and inorganic materials, and optional features like autoMatAlert and autoNarcAlert add automated alerts for materials and narcotics.

This gives operators an additional layer of detection support beyond what they can identify visually.

Is the AutoClear 5333 suitable for permanent checkpoints as well as temporary events?

Yes. The system’s robust steel frame construction and STAC certification make it dependable for permanent installations at corporate, government, and critical infrastructure sites, while its compact size and mobility make it equally practical for temporary deployments and events.

Whether installed permanently or moved between locations, this advanced baggage x-ray machine delivers reliable screening performance.
